Konica Minolta KM1024aSHE printhead
$2,573.00
Your order will be shipped out in 24 hours when it is available in stock.
The default shipping way is DHL or FedEx express.
If you enquire more quantity. please send email to : sales@digitalprinthead.com
Share:
- For high laydown applications with a 6pl native drop size, the new KM1024aSHE is perfect. Combining the same slim architecture as the KM1024iSHE but with analogue drive, Konica Minolta have developed a significantly more powerful product.
- Simple to integrate, tough and reliable with good fluid compatibility
- Available in 6pl drop size, suitable for solvent, oil and UV inks.
- Uses the same compact footprint as the digital-driven version, it provides a realistic upgrade path for existing users.
- If combined with the latest compact recirculating printhead from Konica Minolta, the KM1024aLHG-RC, using the same analogue drive, a very powerful combination of high lay down white or varnish can with vibrant high-quality graphics be achieved
| Available ink types | UV/Solvent |
| Technology | Independent channel, on-demand piezo |
| Number of nozzles | 1024 (256 x 4 rows) |
| Channel resolution | 70.5μm pitch (360 dpi: 4 rows x 90 dpi) |
| Grey scale | 8 levels |
| Typical frequency | TBC |
| Drive voltage | 17 +/- 3V |
| Printing width | 72.084 mm |
| Overall row spacing | 2.82 mm |
| Drop velocity | 7.0 m/sec |
| Dimensions | Height 97.0 mm x Width 18.0 mm x Length 131.0 mm |
| Weight | Less than 150 g |
| Drop size | 6pl |
| Max frequency | 40.0 kHz |
| Weight | 1.6 kg |
|---|---|
| Dimensions | 30 × 30 × 20 cm |
| Printhead brands | Konica |
